| Lumens: | 128LMW, 5120-7680 lumens |
| CCT selectable: | Yes (3 cct) |
| Operating Temperature: | -4°F - 122°F |
| Material: | Die Cast Aluminum |
| Lens: | UV resistant PC lens |
| Input voltage: | 120V-277V |
| DLC: | Yes |
| Ratings: | IP65/IK08 |
| CRI: | >70 |
| Surge Protection: | 2.5Kv |
| Size (inch): | 16.15"(H) 9.54"(ø) |
Please Fill The Required Detail's
Specification
| Catalog No. | Lumens Rated | Watt Rated | LPW | CCT | Dim |
| EA-001B-040-CCT | 5120Lm | 70/80/100W | 128LMW | 3500/4000/5000K | 0-10V |
| EA-002B-050-CCT | 6400Lm | 100/120/150W | 128LMW | 4000/5000/6000K | 0-10V |
| EA-003B-060-CCT | 7680Lm | 120/150/200W | 128LMW | 4000/5000/6000K | 0-10V |
| EA-001B-040-CCT-P | 5120Lm | 70/80/100W | 128LMW | 3500/4000/5000K | Photocell on/off |
| EA-002B-050-CCT-P | 6400Lm | 100/120/150W | 128LMW | 4000/5000/6000K | Photocell on/off |
| EA-003B-060-CCT-P | 7680Lm | 120/150/200W | 128LMW | 4000/5000/6000K | Photocell on/off |
