150LMW, 3300-8250 lumens
Power selectable: Yes (3 wattage)
CCT selectable: Yes (3 cct)
Operating Temperature: -4°F - 122°F
Input voltage: 120V-277V
DLC: Yes
Ratings: IP20
CRI: >80
Surge Protection: 2.5Kv
Electric scalability: 0-10V dimming. Radar, infrared, microwave sensor
Size (inch): 2x2 1.4"(H) 23.7"(W) 23.7"(L)
1x4 1.4"(H) 12"(W) 47.8"(L)
2x4 1.4"(H) 23.7"(W) 47.8"(L)
Please Fill The Required Detail's
Specification
| Catalog No. | Lumens Rated | Watt Rated | LPW | CCT | Dim |
| EY-001C-040-3CCT-H | 3300-6600Lm | 20/30/40W | 150LPW | 3500/4000/5000K | 0-10V |
| EY-002C-040-3CCT-H | 3300-6600Lm | 20/30/40W | 150LPW | 3500/4000/5000K | 0-10V |
| EY-003C-050-3CCT-H | 4950-8250Lm | 30/40/50W | 150LPW | 3500/4000/5000K | 0-10V |
